| size | 50 x 25 | 50 x 50 | 75 x 50 | 75 x 75 | 100 x 50 | 100 x 75 | 100 x 100 | 150 x 50 |
|---|---|---|---|---|---|---|---|---|
| 1 comp | AGTT21/SB | AGTT22/SB | AGTT32/SB | AGTT33/SB | AGTT42/SB | AGTT43/SB | AGTT44/SB | AGTT62/SB |
| 2 comp | AGTT21/2/SB | AGTT22/2/SB | AGTT32/2/SB | AGTT33/2/SB | AGTT42/2/SB | AGTT43/2/SB | AGTT44/2/SB | AGTT62/2/SB |
| 3 comp | AGTT21/3/SB | AGTT22/3/SB | AGTT32/3/SB | AGTT33/3/SB | AGTT42/3/SB | AGTT43/3/SB | AGTT44/3/SB | AGTT62/3/SB |
| 4 comp | AGTT21/4/SB | AGTT22/4/SB | AGTT32/4/SB | AGTT33/4/SB | AGTT42/4/SB | AGTT43/4/SB | AGTT44/4/SB | AGTT62/4/SB |
| size | 150 x 75 | 150 x 100 | 150 x 150 | 200 x 50 | 200 x 100 | 225 x 50 | 225 x 75 | 225 x 100 |
| 1 comp | AGTT63/SB | AGTT64/SB | AGTT66/SB | AGTT82/SB | AGTT84/SB | AGTT92/SB | AGTT93/SB | AGTT94/SB |
| 2 comp | AGTT63/2/SB | AGTT64/2/SB | AGTT66/2/SB | AGTT82/2/SB | AGTT84/2/SB | AGTT92/2/SB | AGTT93/2/SB | AGTT94/2/SB |
| 3 comp | AGTT63/3/SB | AGTT64/3/SB | AGTT66/3/SB | AGTT82/3/SB | AGTT84/3/SB | AGTT92/3/SB | AGTT93/3/SB | AGTT94/3/SB |
| 4 comp | AGTT63/4/SB | AGTT64/4/SB | AGTT66/4/SB | AGTT82/4/SB | AGTT84/4/SB | AGTT92/4/SB | AGTT93/4/SB | AGTT94/4/SB |
| size | 225 x 150 | 225 x 225 | 300 x 50 | 300 x 75 | 300 x 100 | 300 x 150 | 300 x 225 | 300 x 300 |
| 1 comp | AGTT96/SB | AGTT99/SB | AGTT122/SB | AGTT123/SB | AGTT124/SB | AGTT126/SB | AGTT129/SB | AGTT1212/SB |
| 2 comp | AGTT96/2/SB | AGTT99/2/SB | AGTT122/2/SB | AGTT123/2/SB | AGTT124/2/SB | AGTT126/2/SB | AGTT129/2/SB | AGTT1212/2/SB |
| 3 comp | AGTT96/3/SB | AGTT99/3/SB | AGTT122/3/SB | AGTT123/3/SB | AGTT124/3/SB | AGTT126/3/SB | AGTT129/3/SB | AGTT1212/3/SB |
| 4 comp | AGTT96/4/SB | AGTT99/4/SB | AGTT122/4/SB | AGTT123/4/SB | AGTT124/4/SB | AGTT126/4/SB | AGTT129/4/SB | AGTT1212/4/SB |
Description
RMS offer a comprehensive range of screw bush returned edge surface trunking single or multi compartment to British Standard EN 50085 – 1:2006 + A1: 2011 unless otherwise stated
All cable trunking lengths and accessories will be supplied as screw bush with the following:
Various sizes of cable trunking body and lid will be made from 1.0mm nominal
All trunking bodies have a 15mm wide return flange
All trunking lids are supplied 3 metre long
‘U’ type connectors to be supplied on single compartment trunking
‘Fish-Plate’ type connectors are supplied on multi-compartment trunking
Screws for lids, connectors and accessories to be M5x12mm screw bush
