| size | 50 x 25 | 50 x 50 | 75 x 50 | 75 x 75 | 100 x 50 | 100 x 75 | 100 x 100 | 150 x 50 |
|---|---|---|---|---|---|---|---|---|
| 1 comp | AFBT21/SB | AFBT22/SB | AFBT32/SB | AFBT33/SB | AFBT42/SB | AFBT43/SB | AFBT44/SB | AFBT62/SB |
| 2 comp | AFBT21/2/SB | AFBT22/2/SB | AFBT32/2/SB | AFBT33/2/SB | AFBT42/2/SB | AFBT43/2/SB | AFBT44/2/SB | AFBT62/2/SB |
| 3 comp | AFBT21/3/SB | AFBT22/3/SB | AFBT32/3/SB | AFBT33/3/SB | AFBT42/3/SB | AFBT43/3/SB | AFBT44/3/SB | AFBT62/3/SB |
| 4 comp | AFBT21/4/SB | AFBT22/4/SB | AFBT32/4/SB | AFBT33/4/SB | AFBT42/4/SB | AFBT43/4/SB | AFBT44/4/SB | AFBT62/4/SB |
| size | 150 x 75 | 150 x 100 | 150 x 150 | 200 x 50 | 200 x 100 | 225 x 50 | 225 x 75 | 225 x 100 |
| 1 comp | AFBT63/SB | AFBT64/SB | AFBT66/SB | AFBT82/SB | AFBT84/SB | AFBT92/SB | AFBT93/SB | AFBT94/SB |
| 2 comp | AFBT63/2/SB | AFBT64/2/SB | AFBT66/2/SB | AFBT82/2/SB | AFBT84/2/SB | AFBT92/2/SB | AFBT93/2/SB | AFBT94/2/SB |
| 3 comp | AFBT63/3/SB | AFBT64/3/SB | AFBT66/3/SB | AFBT82/3/SB | AFBT84/3/SB | AFBT92/3/SB | AFBT93/3/SB | AFBT94/3/SB |
| 4 comp | AFBT63/4/SB | AFBT64/4/SB | AFBT66/4/SB | AFBT82/4/SB | AFBT84/4/SB | AFBT92/4/SB | AFBT93/4/SB | AFBT94/4/SB |
| size | 225 x 150 | 225 x 225 | 300 x 50 | 300 x 75 | 300 x 100 | 300 x 150 | 300 x 225 | 300 x 300 |
| 1 comp | AFBT96/SB | AFBT99/SB | AFBT122/SB | AFBT123/SB | AFBT124/SB | AFBT126/SB | AFBT129/SB | AFBT1212/SB |
| 2 comp | AFBT96/2/SB | AFBT99/2/SB | AFBT122/2/SB | AFBT123/2/SB | AFBT124/2/SB | AFBT126/2/SB | AFBT129/2/SB | AFBT1212/2/SB |
| 3 comp | AFBT96/3/SB | AFBT99/3/SB | AFBT122/3/SB | AFBT123/3/SB | AFBT124/3/SB | AFBT126/3/SB | AFBT129/3/SB | AFBT1212/3/SB |
| 4 comp | AFBT96/4/SB | AFBT99/4/SB | AFBT122/4/SB | AFBT123/4/SB | AFBT124/4/SB | AFBT126/4/SB | AFBT129/4/SB | AFBT1212/4/SB |
Description
RMS offer a comprehensive range of standard returned edge surface trunking single or multi compartment to British Standard EN 50085 – 1:2006 + A1: 2011 unless otherwise stated
All cable trunking lengths and accessories will be supplied as screw bush with the following:
Various sizes of cable trunking body and lid will be made from 1.0mm nominal
All trunking bodies have a 15mm wide return flange
All trunking lids are supplied 3 metre long
‘U’ type connectors to be supplied on single compartment trunking
‘Fish-Plate’ type connectors are supplied on multi-compartment trunking
Screws for lids, connectors and accessories to be M5x12mm screw bush
